DESIGN FACILITIES – CAD / CAM

1. CATIA –V5 AutoCAD ALMA for 3D Laser Cutting Work NC for CNC Programming

Product innovation is often the result of new combinations of design, material, tooling and process. Product development capabilities at Sigma include design work stations that support a CAD/CAM software including Unigraphics and IDEAS. These are mainly used to conduct preliminary studies of the basic designs and then further analysis is carried out on the results, in order to check parameters and specifications. A common prerequisite to the design process of any part is to first determine its exact operating parameters. This is done by first determining the detailed, technical specifications of the part and its ability to perform for a certain length of time with minimal wear. Availability of this information is followed by an elaboration of alternative solutions to the design problem keeping in mind the manufacturability of the product. This includes the ease to manufacture the product for a particular design as well as the cost involved in producing that design. The final design is filtered using the relevant simulation system (CAD) that uses built-in modules to test the individual variations (in geometry and materials) for optimal conformance to the specified requirements.
